THE BEAM PATTERN
If you’re looking for a driving light that offers near-field spread, keep moving, this is not that. The optical properties of the hooded reflector design is best described as high-beam on steroids. The ST-X excels in the high-speed, high-way application when mid to long-range visibility is critical.
Significantly minimizes adverse reflection from road signs
Controlled vertical spread minimizes reflections off of high-mounted road signs.
KEY FEATURES
- 4x 15W LEDs
- LED Parking / Position Light Function (Amber or White built-in)
- Breather allows pressure equalisation when rapid heat up and cool down cycles occur
- Anodized Polyester Powder Coat
- Weatherproof Deutsch® DTP Connector
- Includes adjustable Side brackets & Sliding bottom brackets
- Includes our Easy-Fit Plug & Play High Beam Wiring Harness with HB3 & H4 adapter (Compatible with both negative and positive switched vehicles)
- Protected against reverse polarity
- Shockproof, IP68 waterproof, UV Shielded
- Protected Against RFI / EMC Interference
- Voltage & current surge protection
- Pulse Width Modulation Thermal Management
TECH SPECS
VOLTAGE | 9-36V |
AMPERES | 4.08A |
POWER | 48.96W |
LUMENS | 2100LM |
COLOUR TEMPERATURE | 5000K |
AMP RATING | 0.1a |
PHOTOMETRIC DATA | 1 lux @ 429m |
LENS MATERIAL | Optical grade, Hard-Coated LEXAN |
HOUSING MATERIAL | 6063 Extrusion |
INGRESS PROTECTION | IP68 |
CANDELAS | 184,164 |
CONNECTOR | 60cm Cable with DTP 4in |
CERTIFICATES | R112, ref. 45 and R10 |
LIFESPAN | 50, 000hrs (LM80) |
OPERATING TEMP | -40°C ~ +60°C |
PRODUCT WEIGHT | 1.6kg |
SHIPPING WEIGHT | 2.1kg |
WHAT’S INCLUDED
- 1 x 12 Inch ST-X-20L LED Light Bar
- 2 x Steel Side Brackets
- 2 x Steel Sliding Brackets
- Easy-Fit High Beam Wiring Kit | HB3 & H4 piggy-back included.
- Comprehensive 304 Stainless Steel fasteners
- Wiring Instructions
